Hummer H2 I facelift (2007-2009) ser data comm Wiring diagram
This page shows the only wiring diagram for the component.ser data comm, which is found in the car Hummer H2 I facelift (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ser data comm (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
DATA COMMUNICATION
DK GRN WIRE
HI SER DATA BUS+
LO GMLAN SER DATA
LO GMLAN SERIAL DATA
LT BLU WIRE
RED/WHT WIRE
SER DATA COMM
TAN WIRE
TAN/BLK WIRE
TRANSFER CASE SHIFT CONTROL MODULE (BEHIND HEADLIGHT SWITCH)
TRANSMISSION CONTROL MODULE (TCM) (PART OF AUTOMATIC TRANSMISSION)
W/ OFF ROAD SUSPENSION CHASSIS PACKAGE
W/ ONSTAR
W/O OFF ROAD SUSPENSION CHASSIS PACKAGE
W/O ONSTAR
Go to component -> Computer data lines circuit (2 of 2) -> SER DATA COMM
