Wiring diagram pnk low reference (1 of 2)
AIR BAG AUX- IGN HVAC-IGN FUSE 34 FUSE 41
B+ IGN I/P MOD DISABLE SW SIG I/P MOD SUPP IND CTRL PNK WIRE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISABLE SWITCH
DK GRN WIRE
DRIVER SEAT BELT BUCKLE
DRIVER SEAT BELT PRETENSIONER (PART OF DRIVER SEAT BELT RETRACTOR ASSEMBLY)
DRIVER SEAT BELT SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES AIR BAG BATT FUSE 38
HOT IN ON OR START
INFLATABLE RESTRAINT I/P MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER LEFT FRONT SEAT)
INFLATABLE RESTRAINT VEHICLE
LEFT I/P JUNCTION BLOCK
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK LOW REFERENCE WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED/WHT WIRE
ROLL OVER SENS HI SIG L SEAT BELT SW
ROLLOVER SENSOR (BELOW CENTER CONSOLE IN FRONT OF AUDIO AMPLIFIER)
SHORTING BAR
TAN WIRE
TAN/BLK WIRE
TAN/ORG WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPT, NEAR BATTERY)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> PNK LOW REFERENCE WIRE
Wiring diagram pnk low reference (2 of 2)
2 3 1 OFF AUTO
5 9 13 DRV DOOR KEY SW LO GMLAN SER DATA LF DOOR AJAR SW
8 17 12 PARK LAMPS SIG HEADLAMPS OFF SIG HEADLAMPS ON SIG
AUTO
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH (MOUNTED TO LOWER LEFT SIDE OF MASTER CYLINDER)
BRAKE/
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER DOOR LATCH ASSEMBLY (INSIDE DRIVER DOOR BELOW OUTSIDE DOOR HANDLE)
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER SEAT BELT BUCKLE
DRIVER SEAT BELT SWITCH
GND LVL SIG
GRY/BLK WIRE
HEADLAMP, PANEL DIMMER SWITCH
HOT AT ALL TIMES
IGN
IGNITION SWITCH
IND BRAKE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER LEFT FRONT SEAT)
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE 39
KEY-IN IGNITION SWITCH
L SEAT BELT SW
LEFT I/P JUNCTION BLOCK
LO GMLAN SER DATA
LOGIC
LT BLU WIRE
NCA WIRE
OFF
PARK BRAKE SWITCH (PART OF PARKING BRAKE ASSEMBLY)
PARK BRK SW SIG
PARK HEAD
PNK LOW REFERENCE WIRE
PNK WIRE
PNK/BLK WIRE
PPL
RADIO
RED/WHT WIRE
SEAT BELT IND
SERIAL B+ DATA
SERIAL DATA
TAN/WHT WIRE
TIRE PRESSURE IND
WHT WIRE
YEL WIRE
Go to component -> Warning systems circuit -> PNK LOW REFERENCE WIRE
