Ground distribution circuit for Hummer H2 I (2002-2007)

A/C COMPRESSOR CLUTCH A/C LOW PRESSURE SWITCH BATTERY BLK WIRE BLK/WHT WIRE BRAKE FLUID LEVEL SWITCH ENGINE OIL LEVEL SWITCH FUEL PUMP RELAY GRILLE GUARD OFF-ROAD LAMP HIGH HORN IGN 1 RELAY IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL 7 IGNITION COIL 8 LEFT DAYTIME RUNNING LAMP (DRL) LEFT FRONT PARK/TURN SIGNAL LAMP LEFT HEADLAMP LOW HORN NCA WIRE POWERTRAIN CONTROL MODULE RIGHT DAYTIME RUNNING LAMP (DRL) RIGHT FRONT PARK/TURN SIGNAL LAMP RIGHT HEADLAMP THROTTLE ACTUATOR CONTROL (TAC) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) WHT WIRE WINDSHIELD WASHER FLUID LEVEL SWITCH

BLK WIRE DRIVER MEMORY SEAT MODULE ELECTRONIC BRAKE CONTROL MODULE (EBCM) FRONT PASSENGER LUMBAR/ SEAT BOLSTER SWITCH FRONT PASSENGER SEAT ADJUSTER SWITCH FUEL PUMP GRN WIRE GRY WIRE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE LEFT "B" PILLAR COURTESY LAMP LEFT BACKUP LAMP LEFT REAR DOOR COURTESY LAMP LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR HEATED SEAT CONTROL MODULE LEFT REAR HEATED SEAT ELEMENT LEFT REAR TURN SIGNAL LAMP LEFT REAR WINDOW SWITCH LEFT TAIL/STOP LAMP NCA WIRE REAR LAMPS JUNCTION BLOCK RIGHT "B" PILLAR COURTESY LAMP RIGHT BACKUP LAMP RIGHT REAR DOOR COURTESY LAMP RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR HEATED SEAT CONTROL MODULE RIGHT REAR HEATED SEAT ELEMENT RIGHT REAR TURN SIGNAL LAMP RIGHT REAR WINDOW SWITCH RIGHT TAIL/STOP LAMP TRAILER CONNECTOR TRANSFER CASE SHIFT CONTROL MODULE W/ FRONT, REAR HEATED SEATS

A/T SHIFT LEVER POSITION INDICATOR LAMP A/T SHIFT LOCK SOLENOID BLK WIRE BLOWER MOTOR CIGAR LIGHTER CONSOLE AUXILIARY POWER OUTLET DATA LINK CONNECTOR DRIVER DOOR MODULE FLOOR SHIFT ASSEMBLY ELECTRIC PARK LOCK SOLENOID FRONT 1 AUXILIARY POWER OUTLET FRONT 2 AUXILIARY POWER OUTLET FRONT PASSENGER DOOR MODULE GARAGE DOOR OPENER HARN) HVAC CONTROL MODULE I/P FUSE BLOCK (LOWER LEFT SIDE SIDE OF DASH) DOOR UNLOCK RELAY DOOR LOCK RELAY I/P JUNCTION BLOCK (LOWER RIGHT SIDE OF DASH) I/P RELAY BLOCK (NEAR LEFT KICK PANEL) INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH INSIDE AIR TEMPERATURE SENSOR ASSEMBLY INSIDE REARVIEW MIRROR INSTRUMENT PANEL CLUSTER TOW/HAUL SWITCH HEADLAMP SWITCH LEFT FRONT CLEARANCE LAMP LEFT FRONT COURTESY/ READING LAMP LEFT INNER ROOF OFF- ROAD LAMP LEFT OUTER ROOF OFF- ROAD LAMP LEFT REAR HEATED SEAT SWITCH LEFT VANITY MIRROR LAMP NCA WIRE OFF ROAD LAMPS RELAY 2 OFF ROAD LAMPS SWITCH RIDE HEIGHT SWITCH RIGHT FOOTWELL COURTESY LAMP I/P COMPARTMENT LAMP RIGHT FRONT CLEARANCE LAMP RIGHT FRONT COURTESY/ READING LAMP THIRD ROW DOME/ READING LAMP RIGHT REAR HEATED SEAT SWITCH RIGHT VANITY MIRROR LAMP ROOF MARKER LAMP ROOF MARKER LAMP ROOF MARKER LAMP SECOND ROW DOME/ READING LAMP SUNROOF ASSEMBLY SUNROOF RELAY TRANSFER CASE SHIFT CONTROL SWITCH W/ OFF-ROAD LAMPS W/O OFF-ROAD LAMPS WINDSHIELD WIPER MOTOR MODULE

AUDIO AMPLIFIER BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE DATA LINK CONNECTOR HEADLAMP, PANEL DIMMER SWITCH HVAC CONTROL MODULE I/P RELAY BLOCK (NEAR LEFT KICK PANEL) IGNITION KEY ALARM SWITCH IGNITION KEY LOCK SOLENOID INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER LOWER LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY LOWER RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY NCA WIRE RADIO REAR SEAT AUDIO (RSA) CONTROL TAN WIRE TRACTION CONTROL SWITCH TURN SIGNAL/ HAZARD FLASHER MODULE TURN SIGNAL/ MULTIFUNCTION SWITCH UPPER LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY UPPER RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) WHT WIRE

AIR SUSPENSION COMPRESSOR AIR SUSPENSION MODULE BLK WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) LEFT LICENSE LAMP LEFT LIFTGATE AJAR SWITCH LEFT MIDGATE LATCH LEFT MIDGATE LATCH RELEASE SWITCH LEFT REAR CLEARANCE LAMP LEFT REAR ROOF MARKER LAMP LIFT GATE LOCK RELAY MIDDLE REAR ROOF MARKER LAMP MIDGATE CONTROL MODULE NCA WIRE REAR AUXILIARY POWER OUTLET REAR WINDOW DEFOGGER GRID REAR WINDOW DEFROSTER GRID REAR WINDOW WIPER MOTOR RIGHT LICENSE LAMP RIGHT LIFTGATE AJAR SWITCH RIGHT MIDGATE LATCH RIGHT MIDGATE LATCH RELEASE SWITCH RIGHT REAR CLEARANCE LAMP RIGHT REAR ROOF MARKER LAMP SUT
