Hummer H2 I (2002-2007) hot ignition 1 relay energized Wiring diagram

ABS FUSE FUSE ABS IND. BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (ON TOP LEFT SIDE OF DASH, ABOVE I/P FUSE BLOCK) BRAKE FLUID LEVEL SWITCH (ON LEFT SIDE OF BRAKE FLUID RESERVOIR) BRAKE IND BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH, BELOW STEERING COLUMN) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) ETC/ECM FUSE GRY WIRE HOT AT ALL TIMES HOT IGNITION 1 RELAY ENERGIZED HOT IN RUN OR START I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH) STOP FUSE IGN 1 IGN E FUSE ILLUM INSTRUMENT PANEL CLUSTER LF WHL SPD LF WHL SPD LR WHL SPD LR WHL SPD LNG RATE LO REF LONGITUDINAL ACCELEROMETER (BEHIND CENTER OF DASH) LT BLU WIRE LT GRN WIRE ORG/ WIRE PARK BRAKE PARK BRAKE SWITCH PNK PNK WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE RF WHL SPD RF WHL SPD STOP LP SW RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (ON RIGHT REAR WHEEL HUB ASSEMBLY) SERIAL DATA SPLICE PACK STOP LP FUSE STOP- LAMP SWITCH (ON TOP OF BRAKE PEDAL BRACKET) TAN WIRE TRACTION CONTROL IND TRACTION CONTROL OFF IND TRACTION CONTROL SWITCH TRANSFER CASE SHIFT CONTROL MODULE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT, NEAR BATTERY) WHT WIRE YEL WIRE
