Hummer H2 I (2002-2007) height control sw ind control wiring diagram
This page shows the only wiring diagram for the component.height control sw ind control, which is found in the car Hummer H2 I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
height control sw ind control wiring diagram (1 of 1)
AIR SUSPENSION MODULE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF INNER FRAME)
FUSE
GARAGE DOOR OPENER
HARN)
HEIGHT CONTROL SW IND CONTROL
HVAC CONTROL ASSEMBLY
I/P RELAY BLOCK (BELOW LEFT SIDE OF DASH, NEAR KICK PANEL)
INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER
LEFT REAR WINDOW SWITCH
ORG/ WIRE
PPL/WHT WIRE
PRNDL LAMP 2 PRNDL LAMP 1
REAR WINDOW WIPER/WASHER SWITCH
RED WIRE
RIDE HEIGHT SWITCH
RIGHT REAR HEATED SEAT SWITCH LEFT REAR HEATED SEAT SWITCH
RIGHT REAR WINDOW SWITCH
STEERING WHEEL CONTROLS
SUNROOF SWITCH
TO FLOOR CONSOLE HARN
TOW/HAUL SWITCH
TRACTION CONTROL SWITCH
TRACTION IND CONTROL
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> HEIGHT CONTROL SW IND CONTROL
