Car Wiring Diagrams for Headlights circuit, canada for Honda S2000 I (2004-2009)

ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE INDICATOR LIGHT COMBINATION LIGHT SWITCH DAYTIME RUNNING LIGHTS (DRL) CONTROL UNIT DIMMER SWITCH LO HI DRL DIODE (UNDER MIDDLE OF DASH) DRL INDICATOR LIGHT ELECTRICAL LOAD DETECTOR UNIT FILTER FLASH TO PASS SWITCH FUSE 27 FUSE 41 FUSE 43 FUSE 44 FUSE 45 FUSE 5 GAUGE ASSEMBLY GRN WIRE GRN/WHT WIRE HEAD OFF HEAD- LIGHT RELAY 2 HEADLIGHT RELAY 1 HEADLIGHT SWITCH HIGH BEAM HIGH BEAM CUT RELAY HIGH BEAM IGNITER HIGH BEAM INDICATOR LIGHT HOT AT ALL TIMES HOT IN ON HOT IN ON W/ ENGINE NOT CRANKING IGNITER INVERTER LEFT HEADLIGHT LOW BEAM MAIN UNDER-HOOD FUSE/RELAY BOX ORG/ WIRE PARK PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER) POWER TOPS SYSTEM RED WIRE RED/BLU WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HEADLIGHT UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 19 WHT WIRE YEL WIRE YEL/BLK WIRE
