Honda S2000 I (2004-2009) right down left up Wiring diagram

This page shows the only wiring diagram for the component.right down left up, which is found in the car Honda S2000 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right down left up (1 of 1)

Wiring diagram right down left up for Honda S2000 I (2004-2009)

Get access

BLK WIRE BLU WIRE BRN WIRE FUSE 19 GRN WIRE HOT IN ON LEFT DOWN RIGHT UP LEFT POWER MIRROR LEFT RIGHT LEFT UP RIGHT DOWN LEFT/RIGHT MOTOR MIRROR SELECTOR SWITCH POWER MIRROR SWITCH RED WIRE RIGHT DOWN LEFT UP RIGHT LEFT RIGHT POWER MIRROR SWITCH 1 SWITCH 2 SWITCH 3 UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF OF DASH) UP/DOWN MOTOR WHT WIRE YEL WIRE

Go to component: -> Power mirrors circuit -> RIGHT DOWN LEFT UP
