Honda S2000 I (2004-2009) passenger's window switch up down Wiring diagram

This page shows the only wiring diagram for the component.passenger's window switch up down, which is found in the car Honda S2000 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger's window switch up down (1 of 1)

Wiring diagram passenger's window switch up down for Honda S2000 I (2004-2009)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE CONVERTIBLE TOP CONTROL UNIT (UNDER RIGHT SIDE OF DASH) DETECT CIRCUIT DN AUTO DN UP DOWN DRIVER'S WINDOW MOTOR (IN DRIVER'S DOOR) DRIVERS WINDOW SWITCH FUSE 17 FUSE 18 FUSE 8 GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON IGS MAIN SWITCH OFF OFF ON ORG/ WIRE PASSENGER'S WINDOW MOTOR (IN PASSENGER'S DOOR) PASSENGER'S WINDOW SWITCH UP DOWN PASSENGERS WINDOW SWITCH POWER WINDOW CONTROL UNIT POWER WINDOW MASTER SWITCH PWDRO RED WIRE SGND PLS UP UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UP DOWN WHT WIRE YEL WIRE

Go to component: -> Power windows circuit -> PASSENGER'S WINDOW SWITCH UP DOWN
