Honda S2000 I (2004-2009) inner side passenger's weight sensor Wiring diagram

This page shows the only wiring diagram for the component.inner side passenger's weight sensor, which is found in the car Honda S2000 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram inner side passenger's weight sensor (1 of 1)

Wiring diagram inner side passenger's weight sensor for Honda S2000 I (2004-2009)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CABLE REEL DRIVER'S AIR BAG DRIVING CIRCUIT GAUGE ASSEMBLY GRN WIRE INNER SIDE PASSENGER'S WEIGHT SENSOR LEFT FRONT IMPACT SENSOR (LOWER FRONT OF LEFT SIDE OF ENGINE COMPT) LT BLU WIRE OUTER SIDE PASSENGER'S WEIGHT SENSOR PASSENGER'S AIR BAG PASSENGER'S AIR BAG PASSENGER'S AIRBAG CUT-OFF INDICATOR PNK WIRE PPL RED WIRE RIGHT FRONT IMPACT SENSOR (LOWER FRONT OF RIGHT SIDE OF ENGINE COMPT) SHORT CONTACT SRS INDICATOR CIRCUIT SRS INDICATOR LIGHT STEERING WHEEL) WHT WIRE YEL WIRE

Go to component: -> Supplemental restraints circuit (2 of 2) -> INNER SIDE PASSENGER'S WEIGHT SENSOR
