Honda S2000 I (2004-2009) ignition key switch/ key light wiring diagram
This page shows the only wiring diagram for the component.ignition key switch/ key light, which is found in the car Honda S2000 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ignition key switch/ key light wiring diagram (1 of 1)
BEEPER
BLK WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION SWITCH
DOOR IND
DRIVER'S DOOR SWITCH (AT LEFT "C" PILLAR)
DRIVER'S SEAT BELT SWITCH (UNDER DRIVER'S SEAT)
DRIVING CIRCUIT
FUSE 25
FUSE 5
GAUGE ASSEMBLY
GRN WIRE
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN ON
IGNITION KEY SWITCH/ KEY LIGHT
KEYLESS DOOR LOCK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
LCD DISPLAY
LOW OIL PRESSURE IND
LT GRN WIRE
ODO/TRIP SWITCH MPH/KM/H SWITCH
OFF HEAD
OIL PRESSURE SWITCH
PARK
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SEAT BELT REMINDER LIGHT
SRS UNIT (BEHIND CENTER OF DASH, BELOW RADIO)
TAILLIGHT RELAY
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
VOLTAGE FEED
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Warning systems circuit -> IGNITION KEY SWITCH/ KEY LIGHT
