Honda S2000 I (2004-2009) a/c condenser fan relay Wiring diagrams
This page contains all the electrical diagrams for the component. a/c condenser fan relay, in which he is found in the car Honda S2000 I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c condenser fan relay (1 of 2)
A/C CONDENSER FAN MOTOR (AT LEFT FRONT OF ENGINE COMPARTMENT)
A/C CONDENSER FAN RELAY
A/C ON
A/C ON REQUEST
A/C PRESSURE SWITCH HIGH (ON RECEIVER DRIER, BEHIND CENTER OF FRONT BUMPER)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
ECT SENSOR 1 (TOP REAR OF ENGINE)
ECT SENSOR 2 (LOWER LEFT OF RADIATOR)
ENGINE CONTROL MODULE (ECM) (BEHIND LEFT KICK PANEL)
FAN CTRL
FUSE 20
FUSE 57
FUSE 58
GRN WIRE
GRN/YEL WIRE
HEATER CONTROL PANEL
HOT AT ALL TIMES
HOT IN ON WITH ENGINE NOT CRANKING
MAIN UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR
OF ENGINE COMPARTMENT)
RADIATOR FAN MOTOR (AT RIGHT FRONT OF ENGINE COMPARTMENT)
RADIATOR FAN RELAY
RED/WHT WIRE
REQUEST
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
Go to component -> Cooling fan circuit -> A/C CONDENSER FAN RELAY
Wiring diagram a/c condenser fan relay (2 of 2)
A/C CONDENSER FAN MOTOR (AT LEFT FRONT OF ENGINE COMPARTMENT)
A/C CONDENSER FAN RELAY
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR (UNDER RIGHT SIDE OF DASH)
BLOWER MOTOR RELAY
BLOWER POWER TRANSISTOR (UNDER RIGHT SIDE OF DASH)
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
FROM A/C COMPRESSOR CLUTCH RELAY (DIAGRAM 1 OF 2)
FUSE 56
FUSE 57
FUSE 58
GRN WIRE
HOT AT ALL TIMES
MAIN UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPARTMENT)
RADIATOR FAN MOTOR (AT RIGHT FRONT OF ENGINE COMPARTMENT)
RADIATOR FAN RELAY
RED WIRE
SOLID STATE
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> A/C CONDENSER FAN RELAY
