Honda S2000 AP2 facelift (2003-2009) right brake/ side marker/ taillight Wiring diagram
This page shows the only wiring diagram for the component.right brake/ side marker/ taillight, which is found in the car Honda S2000 AP2 facelift (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right brake/ side marker/ taillight (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
COMBINATION SWITCH
FUSE 23
FUSE 47
FUSE 49 FUSE/ RELAY BOX (AT RIGHT REAR OF ENGINE COMPT)
FUSE 7
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HEAD
HEADLIGHT SWITCH
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON
LEFT
LEFT BRAKE LIGHT (LED)
LEFT BRAKE/ SIDE MARKER/ TAILLIGHT
LEFT FRONT PARKING LIGHT/ SIDE MARKER LIGHT LEFT REAR TURN SIGNAL LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT SIDE TURN SIGNAL LIGHT
LEFT TAIL- LIGHT (LED)
LEFT TURN INDICATOR LIGHT
LICENSE PLATE LIGHT
MAIN UNDER- HOOD FUSE/ RELAY BOX (AT RIGHT REAR OF ENGINE COMPT)
MAIN UNDER-HOOD
OFF PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT
RIGHT BRAKE LIGHT (LED)
RIGHT BRAKE/ SIDE MARKER/ TAILLIGHT
RIGHT FRONT PARKING LIGHT/ RIGHT REAR TURN SIGNAL LIGHT
RIGHT FRONT TURN SIGNAL LIGHT RIGHT SIDE TURN SIGNAL LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT TAIL- LIGHT (LED)
RIGHT TURN INDICATOR LIGHT
SIDE MARKER LIGHT
TAILLIGHT RELAY
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit -> RIGHT BRAKE/ SIDE MARKER/ TAILLIGHT
