Honda S2000 AP2 facelift (2003-2009) r seat belt sw r seat belt sw Wiring diagram

7 9 DLC (UNDER LEFT SIDE OF DASH) BLK WIRE BLK/YEL WIRE BLU (OR WIRE BLU WIRE BRN WIRE DRIVER'S SEAT BELT SWITCH 1) UNBUCKLED 2) BUCKLED (UNDER DRIVER'S SEAT) DRIVER'S SEAT BELT TENSIONER (BELOW LEFT SIDE ROLL BAR UPPER TRIM) DRIVER'S SEAT POSITION SENSOR (UNDER DRIVER'S SEAT) FUSE 1 FUSE 2 FUSE 5 GRD GRN WIRE GROUND GROUND DLC INP/OUTP GRY WIRE HOT IN ON L FR IMP R FR IMP L SEAT BELT SW L SEAT BELT SW LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MES CONNECTOR (ON UNDER-DASH FUSE/RELAY BOX) ODUS ORG/ WIRE PASSENGER'S SEAT BELT SWITCH 1) UNBUCKLED 2) BUCKLED (UNDER PASSENGER'S SEAT) PASSENGER'S SEAT BELT TENSIONER (BELOW RIGHT SIDE ROLL BAR UPPER TRIM) PNK WIRE PPL R SEAT BELT SW R SEAT BELT SW RED WIRE SHORT CONTACT SRS UNIT (BEHIND CENTER OF DASH, BELOW RADIO) SUPPLY SWIG SWIP SWOG SWOP UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WEIGHT SENS L FR IMP R FR IMP IGN INP (VA) IGN INP (VB) WHT WIRE YEL WIRE
