Honda S2000 AP2 facelift (2003-2009) left brake light/ side marker/ taillight Wiring diagram
This page shows the only wiring diagram for the component.left brake light/ side marker/ taillight, which is found in the car Honda S2000 AP2 facelift (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left brake light/ side marker/ taillight (1 of 1)
AUDIO UNIT
BLK WIRE
BLOWER POWER TRANSISTOR
CONVERTIBLE TOP CONTROL UNIT
CRUISE CONTROL MAIN SWITCH
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LATCH
DRL CONTROL UNIT
ENGINE
EPS CONTROL UNIT
GAUGE ASSEMBLY
HEATER CONTROL PANEL
INVERTER
KEYLESS DOOR LOCK CONTROL UNIT
LEFT BRAKE LIGHT/ SIDE MARKER/ TAILLIGHT
LEFT HEADLIGHT LOW BEAM
LEFT REAR TURN SIGNAL LIGHT LEFT BACK-UP LIGHT
LICENSE PLATE LIGHT RIGHT BACK-UP LIGHT
MES CONNECTOR
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RADIO REMOTE SWITCH PASSENGER'S WINDOW SWITCH
REAR WINDOW DEFOGGER SWITCH
RIGHT BRAKE LIGHT/ SIDE MARKER/ TAILLIGHT
RIGHT HEADLIGHT LOW BEAM
RIGHT REAR TURN SIGNAL LIGHT
SWITCH
USA
VSA OFF SWITCH
Go to component: -> Ground distribution circuit (3 of 3) -> LEFT BRAKE LIGHT/ SIDE MARKER/ TAILLIGHT
