Honda S2000 AP2 facelift (2003-2009) drl control unit Wiring diagrams
This page contains all the electrical diagrams for the component. drl control unit, in which he is found in the car Honda S2000 AP2 facelift (2003-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
drl control unit wiring diagram (1 of 3)
AUDIO UNIT
BLK WIRE
BLOWER POWER TRANSISTOR
CONVERTIBLE TOP CONTROL UNIT
CRUISE CONTROL MAIN SWITCH
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LATCH
DRL CONTROL UNIT
ENGINE
EPS CONTROL UNIT
GAUGE ASSEMBLY
HEATER CONTROL PANEL
INVERTER
KEYLESS DOOR LOCK CONTROL UNIT
LEFT BRAKE LIGHT/ SIDE MARKER/ TAILLIGHT
LEFT HEADLIGHT LOW BEAM
LEFT REAR TURN SIGNAL LIGHT LEFT BACK-UP LIGHT
LICENSE PLATE LIGHT RIGHT BACK-UP LIGHT
MES CONNECTOR
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RADIO REMOTE SWITCH PASSENGER'S WINDOW SWITCH
REAR WINDOW DEFOGGER SWITCH
RIGHT BRAKE LIGHT/ SIDE MARKER/ TAILLIGHT
RIGHT HEADLIGHT LOW BEAM
RIGHT REAR TURN SIGNAL LIGHT
SWITCH
USA
VSA OFF SWITCH
Go to component -> Ground distribution circuit (3 of 3) -> DRL CONTROL UNIT
drl control unit wiring diagram (2 of 3)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDEN- SER FAN RELAY RADIATOR FAN RELAY
A/F SENSOR RELAY
ALTERNATOR
AUDIO UNIT
AUXILIARY UNDER-HOOD FUSE BOX (AT REAR LEFT OF ENGINE COMPT)
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRAKE PEDAL POSITION SWITCH
CANADA
CEILING LIGHT/ SPOTLIGHTS
CONVERTIBLE TOP CONTROL UNIT
CONVERTIBLE TOP CONTROL UNIT IMMOBILIZER CONTROL UNIT-RECEIVER
DATA LINK CONNECTOR
DRL CONTROL UNIT
DRL SUB CONTROL UNIT
ELD UNIT
EPS CONTROL UNIT STARTER SOLENOID
FUSE 15
FUSE 16 FUSE 14 FUSE 25
FUSE 17
FUSE 18 FUSE 22
FUSE 24
FUSE 26 FUSE 23
FUSE 27
FUSE 33
FUSE 34
FUSE 41
FUSE 46
FUSE 47
FUSE 49
FUSE 50 FUSE 48
FUSE 51 FUSE 52 FUSE 53
FUSE 55
FUSE 56 FUSE 42 FUSE 54
FUSE 57 FUSE 58
FUSE 59
GAUGE ASSEMBLY AUDIO UNIT HEATER CONTROL PANEL
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HORN RELAY
IGNITION COIL RELAY THROTTLE ACTUATOR CONTROL MODULE
PGM-FI MAIN
POWER WINDOW MASTER SWITCH CONVERTIBLE TOP CONTROL UNIT
REAR WINDOW DEFOGGER RELAY
RED WIRE
STARTER
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TRUNK LID OPENER SWITCH KEYLESS DOOR LOCK CONTROL UNIT TAILLIGHT RELAY
TRUNK LIGHT
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
USA
VSA MODULATOR CONTROL UNIT
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
XM RECEIVER (SATELLITE RADIO)
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> DRL CONTROL UNIT
drl control unit wiring diagram (3 of 3)
A/C CONDENSER FAN RELAY A/C COMPRESSOR CLUTCH RELAY BLOWER MOTOR RELAY
ACCESSORY POWER SOCKET
ACCESSORY POWER SOCKET RELAY (UNDER LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
AUDIO UNIT
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CLUTCH INTERLOCK SWITCH
CONVERTIBLE TOP SWITCH WIPER/ WASHER SWITCH
DRL CONTROL UNIT
ENGINE
FROM FUSE 42 (DIAGRAM 1 OF 3)
FUSE 12
FUSE 20
FUSE 3
FUSE 8
FUSE 9
GRN WIRE
GRN/BLK WIRE
IGNITION SWITCH
INTERMITTENT WIPER RELAY
LOCK ON
LT BLU WIRE
MAIN UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPT)
ORG/ WIRE
POWER WINDOW MASTER SWITCH
RADIATOR FAN RELAY
RADIO REMOTE SWITCH
REAR WINDOW DEFOGGER RELAY POWER MIRROR SWITCH DRL SUB CONTROL UNIT
RECIRC- ULATION CONTROL MOTOR HEATER CONTROL PANEL
RED WIRE
STARTER
STARTER CUT RELAY
STARTER SOLENOID
SWITCH
TO FUSE 1 (DIAGRAM 3 OF 3)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
USA
WHT WIRE
WINDSHIELD WIPER MOTOR
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (2 of 3) -> DRL CONTROL UNIT
