Honda S2000 AP1 (1999-2003) left rear side marker light license plate light Wiring diagram
This page shows the only wiring diagram for the component.left rear side marker light license plate light, which is found in the car Honda S2000 AP1 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side marker light license plate light (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRAKE SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT)
COMBINATION SWITCH
CRUISE CONTROL, ENGINE CONTROLS, ANTI-LOCK BRAKES SYSTEMS
FUSE 23
FUSE 47
FUSE 49
FUSE 7
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HEAD
HEADLIGHT SWITCH
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON
LEFT
LEFT FRONT PARKING LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR SIDE MARKER LIGHT LICENSE PLATE LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE TURN SIGNAL LIGHT
LEFT TAILLIGHT/ BRAKE LIGHT
LEFT TURN INDICATOR LIGHT
MAIN UNDERHOOD FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
OFF PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL LIGHT RIGHT SIDE TURN SIGNAL LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT/ BRAKE LIGHT
RIGHT TURN INDICATOR LIGHT
TAILLIGHT RELAY
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
