Honda S2000 AP1 (1999-2003) high mount brake light accessory power socket Wiring diagram
This page shows the only wiring diagram for the component.high mount brake light accessory power socket, which is found in the car Honda S2000 AP1 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mount brake light accessory power socket (1 of 1)
ABS MODULATOR CONTROL UNIT
AIR PUMP MOTOR
BATTERY
BLK WIRE
BRAIDED WIRE
BRAIDED WIRE BRAIDED WIRE
BRN WIRE
CKF SENSOR SHIELD
CKP SENSOR
DLC
DRIVER'S SEAT BELT SWITCH TRUNK LATCH
EPS CONTROL UNIT
EPS GEAR BOX
FUEL TANK UNIT
GRN WIRE
HIGH MOUNT BRAKE LIGHT ACCESSORY POWER SOCKET
IAC VAVLE
IGNITION COIL 1, IGNITION COIL 2,
IGNITION COIL 3 IGNITION COIL 4
IMMOBILIZER RECEIVER UNIT
KNOCK SENSOR SHIELD PRIMARY
LEFT SIDE ENGINE BLOCK
PGM-FI MAIN RELAY
REAR WINDOW DEFOGGER SUB-HARNESS CONNECTOR
RIGHT SIDE ENGINE BLOCK
SECONDARY
SHIELD
SRS UNIT
TDC 1 SENSOR SHIELD TDC 2 SENSOR SHIELD
VEHICLE SPEED SENSOR
VTEC OIL PRESSURE SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> HIGH MOUNT BRAKE LIGHT ACCESSORY POWER SOCKET
