filter wiring diagram (1 of 4)
AUXILIARY UNDERHOOD FUSE BOX (ON LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
CRUISE CONTROL UNIT (ABOVE BRAKE PEDAL)
DRIVING CIRCUIT (VSS OUT)
ELECTRICAL POWER STEERING (EPS) CONTROL UNIT (RIGHT OF BATTERY)
ENGINE CONTROL MODULE (ECM) (UNDER LEFT SIDE OF DASH)
EPS GEAR BOX (BELOW FRONT CENTER OF ENGINE COMPT)
EPS INDICATOR LIGHT
EPS MOTOR
EPS TORQUE SENSOR (BELOW FRONT CENTER OF ENGINE COMPT)
EPSLD
FILTER
FUSE 33
FUSE 5
GAUGE ASSEMBLY
GND 2 NEP GND 1 PVF SCS
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
LT BLU WIRE
MOTOR+ MOTOR-
NEP
PG +B
PNK WIRE
RED WIRE
TACHOMETER TEST CONNECTOR (BEHIND AUXILIARY UNDERHOOD FUSE BOX)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
VSP PNK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
WLP PS-SIG DLC
YEL WIRE
YEL/BLU WIRE
Go to component -> Electronic power steering circuit -> FILTER
filter wiring diagram (2 of 4)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE INDICATOR LIGHT
COMBINATION LIGHT SWITCH
DIMMER SWITCH
DRL DIODE (BEHIND LEFT SIDE OF DASH)
DRL INDICATOR LIGHT
ELECTRICAL LOAD DETECTOR UNIT
FILTER
FLASH TO PASS SWITCH
FUSE 19
FUSE 41
FUSE 43
FUSE 45
FUSE 5
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HEAD
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHT SWITCH
HIGH BEAM
HIGH BEAM CUT RELAY (UNDER LEFT SIDE OF DASH)
HIGH BEAM INDICATOR LIGHT
HOT AT ALL TIMES
HOT IN ON
IGNITER
INVERTER
LEFT HEADLIGHT
LO HI
LOW BEAM
MAIN UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
NCA WIRE
OFF
ORG/ WIRE
PARK
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
POWER TOPS, INSTRUMENT CLUSTER
RED WIRE
RED/BLU WIRE
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 27
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlight circuit, with drl -> FILTER
filter wiring diagram (3 of 4)
BLK WIRE
BLU WIRE
COMBINATION LIGHT SWITCH
DIMMER SWITCH LO HI
ELECTRICAL LOAD DETECTOR UNIT
FILTER
FLASH TO PASS SWITCH
FUSE 41
FUSE 43
FUSE 45
GAUGE ASSEMBLY
HEAD OFF
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHT SWITCH
HIGH BEAM
HIGH BEAM INDICATOR LIGHT
HOT AT ALL TIMES
IGNITER
INVERTER
LEFT HEADLIGHT
LOW BEAM
MAIN UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
PARK
RED WIRE
RIGHT HEADLIGHT
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl -> FILTER
filter wiring diagram (4 of 4)
BEEPER
BLK WIRE
BLU/RED WIRE
DOOR INDICATOR
DRIVER'S DOOR SWITCH
DRIVER'S SEAT BELT SWITCH
DRIVING CIRCUIT
FILTER
FUSE 25
FUSE 5
GAUGE ASSEMBLY
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
IGNITION KEY SWITCH
INDICATORS
KEYLESS DOOR LOCK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
LCD DISPLAY
ODO/TRIP SWITCH MPH/KM/H SWITCH
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SEAT BELT REMINDER LIGHT
TAILLIGHT RELAY
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
VOLTAGE FEED
WHT/RED WIRE
YEL WIRE
Go to component -> Warning system circuits -> FILTER
