Honda S2000 AP1 (1999-2003) battery ignition Wiring diagrams

This page contains all the electrical diagrams for the component. battery ignition, in which he is found in the car Honda S2000 AP1 (1999-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram battery ignition (1 of 2)

Wiring diagram battery ignition for Honda S2000 AP1 (1999-2003)

Get access

BATTERY IGNITION BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE DISARM SWITCH DOOR OPEN IN TRUNK LATCH IN HOOD SWITCH IN DISARM SW IN COMM UNLOCK CTRL COMM DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LATCH EXTERIOR LIGHTS FUSE 26 FUSE 5 GAUGE ASSEMBLY GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND SECURITY IND IGNITION KEY IN CEILING LIGHTS LIGHT FLASHER HORN CTRL HOOD SWITCH (OPTION) HORN SYSTEM HOT AT ALL TIMES HOT IN ON IGNITION KEY SWITCH INLINE FUSE 1 (UNDER LEFT SIDE OF DASH) INLINE FUSE 2 (UNDER LEFT SIDE OF DASH) INTERIOR LIGHTS KEYLESS DOOR LOCK CONTROL UNIT (UNDER LEFT SIDE OF DASH) LATCH SWITCH TRUNK OPENER SOLENOID LT GRN WIRE NCA WIRE ORG/ WIRE PASSENGER'S DOOR LOCK ACTUATOR PASSENGER'S DOOR SWITCH DRIVER'S DOOR SWITCH PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE SECURITY LED TRUNK LID LATCH TRUNK LID OPENER RELAY (UNDER DRIVER'S SEAT) TRUNK OPEN CTRL TRUNK RELEASE SYSTEM UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH) UNLOCK RELAY (UNDER DRIVER'S SEAT) WARNING SYSTEM WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component: -> Anti-theft circuit -> BATTERY IGNITION

Wiring diagram battery ignition (2 of 2)

Wiring diagram battery ignition for Honda S2000 AP1 (1999-2003)

Get access

BATTERY IGNITION BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE DISARM SWITCH DOOR OPEN IN TRUNK LATCH IN HOOD SWITCH IN DISARM SW IN COMM UNLOCK CTRL COMM DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LATCH EXTERIOR LIGHTS FUSE 26 FUSE 5 GAUGE ASSEMBLY GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND SECURITY IND IGNITION KEY IN CEILING LIGHTS LIGHT FLASHER HORN CTRL HOOD SWITCH (OPTION) HORN SYSTEM HOT AT ALL TIMES HOT IN ON IGNITION KEY SWITCH INLINE FUSE 1 (UNDER LEFT SIDE OF DASH) INLINE FUSE 2 (UNDER LEFT SIDE OF DASH) INTERIOR LIGHTS KEYLESS DOOR LOCK CONTROL UNIT (UNDER LEFT SIDE OF DASH) LATCH SWITCH TRUNK OPENER SOLENOID LT GRN WIRE NCA WIRE ORG/ WIRE PASSENGER'S DOOR LOCK ACTUATOR PASSENGER'S DOOR SWITCH DRIVER'S DOOR SWITCH PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE SECURITY LED TRUNK LID LATCH TRUNK LID OPENER RELAY (UNDER DRIVER'S SEAT) TRUNK OPEN CTRL TRUNK RELEASE SYSTEM UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH) UNLOCK RELAY (UNDER DRIVER'S SEAT) WARNING SYSTEM WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component: -> Power door lock circuit, with anti-theft -> BATTERY IGNITION
