Honda S2000 AP1 (1999-2003) air bag ctrl air bag ctrl data ground ground mes conn input Wiring diagram
This page shows the only wiring diagram for the component.air bag ctrl air bag ctrl data ground ground mes conn input, which is found in the car Honda S2000 AP1 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag ctrl air bag ctrl data ground ground mes conn input (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 AIR BAG CTRL
AIR BAG CTRL AIR BAG CTRL DATA GROUND GROUND MES CONN INPUT
BLK WIRE
BRN WIRE
CABLE REEL
DATA LINK CONNECTOR (PARTIAL) (ON RIGHT SIDE OF AUDIO UNIT)
DRIVER'S AIR BAG INFLATOR
DRIVER'S SEAT BELT TENSIONER (BEHIND DRIVER'S SEAT BELOW ROLL BAR)
FUSE 1
FUSE 2
FUSE 5
GAUGE ASSEMBLY
GRN WIRE
HOT IN ON
IGNITION
INDICATOR CTRL IGNITION MES CONN INPUT DATA AIR BAG CTRL
LT BLU WIRE
NCA WIRE
PASSENGER'S AIR BAG INFLATOR
PASSENGER'S SEAT BELT TENSIONER (BEHIND PASSENGER'S SEAT BELOW ROLL BAR)
PNK WIRE
RED WIRE
SHORT CONTACT
SRS INDICATOR CIRCUIT
SRS INDICATOR LIGHT
SRS MEMORY ERASE SIGNAL CONNECTOR (ON UNDERDASH FUSE/RELAY BOX)
SRS UNIT (BEHIND CENTER OF DASH, BELOW RADIO)
STEERING WHEEL)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
YEL WIRE
Go to component: -> Supplemental restraint circuit -> AIR BAG CTRL AIR BAG CTRL DATA GROUND GROUND MES CONN INPUT
