Car Wiring Diagrams for Blind spot monitoring circuit for Honda Ridgeline II (2016-2021)

BLIND SPOT INFORMATION INDICATOR BLK WIRE BLU WIRE BRN WIRE CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER COMPUTER DATA LINES SYSTEM CPU/MAIN POWER SUPPLY F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE 28 FUSE 29 GAUGE CONTROL MODULE GRN WIRE GRY WIRE INDICATOR DRIVE CIRCUIT JOINT 3 LEFT BSI ALERT INDICATOR LEFT SIDE BSI RADAR UNIT PPL RELAY ENERGIZED RIGHT BSI ALERT INDICATOR RIGHT SIDE BSI RADAR UNIT TAN WIRE UNDER-DASH FUSE/RELAY BOX WHT WIRE
