Car Wiring Diagrams for Automatic a/c circuit for Honda Ridgeline II (2016-2021)

AUTOMATIC LIGHTING CONTROL UNIT-SENSOR AUTOMATIC LIGHTING/RAIN SENSOR BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM FRONT BLOWER MOTOR FRONT POWER TRANSISTOR FUSE 23 FUSE 26 15 FUSE 29 GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HUMIDITY SENSOR HUMIDITY/IN-CAR TEMPERATURE SENSOR IN-CAR TEMPERATURE SENSOR JOINT 3 JOINT 4 LT BLU WIRE LT GRN WIRE PNK WIRE PPL REAR BLOWER MOTOR REAR CONTROL PANEL REAR POWER TRANSISTOR REAR WINDOW DEFOGGER SWITCH REAR WINDOW DEFOGGER SWITCH IND RED WIRE RELAY ENERGIZED RIGHT END OF DASH) TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX W/O AUTOMATIC WIPER W/ AUTOMATIC WIPER W/ A/C POWER OUTLET W/O A/C POWER OUTLET WHT WIRE YEL WIRE

A/C DIODE A A/C DIODE B BLK WIRE BLU WIRE BRN WIRE DRIVER'S AIR MIX CONTROL MOTOR FRONT BLOWER MOTOR RELAY FRONT EVAPORATOR TEMPERATURE SENSOR FUSE 2-6 FUSE 3-1 1-2 FUSE 3-4 1-5 FUSE 8 11 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ PGM-FI MAIN RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MODE CONTROL MOTOR A MODE CONTROL MOTOR B PASSENGER'S AIR MIX CONTROL MOTOR PNK WIRE PPL RADIATOR FAN MOTOR RADIATOR FAN RELAY REAR AIR MIX CONTROL MOTOR REAR BLOWER MOTOR RELAY REAR EVAPORATOR TEMPERATURE SENSOR REAR MODE CONTROL MOTOR RECIRCULATION CONTROL MOTOR RED WIRE RELAY HOLDER A TAN WIRE UNDER-HOOD FUSE/RELAY BOX W/O AC POWER OUTLET WHT WIRE YEL WIRE

A/C COMPRESSOR A/C COMPRESSOR CLUTCH RELAY A/C CONDENSER FAN MOTOR (FRONT OF ENGINE COMPT) A/C CONDENSER FAN RELAY A/C PRESSURE SENSOR BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM ECON MODE IND ECON SWITCH ECT SENSOR 1 (LEFT REAR OF ENGINE) ECT SENSOR 2 ENGINE CONTROLS SYSTEM F-CAN F-CAN TRANSCEIVER FAN CONTROL RELAY FUSE 2-1 FUSE 20 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MICROPROCESSOR (CAN X 2 CHANNEL) OUTSIDE AIR TEMPERATURE SENSOR PCM PNK WIRE PPL RED WIRE RELAY HOLDER C SEATS SYSTEM SUNLIGHT SENSOR (W/O RAIN SENSOR) TAN WIRE TOP OF ENGINE) UNDER-HOOD FUSE/RELAY BOX WARNING DIMMING INDICATOR CIRCUIT DRIVE CIRCUIT WHT WIRE YEL WIRE
