Honda Ridgeline II (2016-2021) w/ cd player unit Wiring diagrams
This page contains all the electrical diagrams for the component. w/ cd player unit, in which he is found in the car Honda Ridgeline II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ cd player unit (1 of 2)
AUDIO REMOTE SWITCH
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CH-
COMPUTER DATA LINE SYSTEM
DISP CHANGE
DOOR LOCKS SYSTEM
FUSE 14
FUSE 29
FUSE 40
GRN WIRE
GRY WIRE
HANG-UP/ BACK
HFL SWITCH/ HEATED STEERING WHEEL SWITCH
HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
MENU
PICK-UP
PNK WIRE
PPL
RED WIRE
SOURCE
TALK
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
VOL DOWN
VOL UP
W/ CD PLAYER UNIT
W/ NAVIGATION
W/O CD PLAYER UNIT
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, w/o amplifier (1 of 5) -> W/ CD PLAYER UNIT
Wiring diagram w/ cd player unit (2 of 2)
AUDIO REMOTE SWITCH
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CH-
COMPUTER DATA LINE SYSTEM
DISP CHANGE
DOOR LOCKS SYSTEM
FUSE 14
FUSE 29
FUSE 40
GRN WIRE
GRY WIRE
HANG-UP/ BACK
HFL SWITCH/ HEATED STEERING WHEEL SWITCH
HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
MENU
PICK-UP
PNK WIRE
PPL
RED WIRE
SOURCE
TALK
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
VOL DOWN
VOL UP
W/ CD PLAYER UNIT
W/ NAVIGATION
W/O CD PLAYER UNIT
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, w/ display audio w/o amplifier (1 of 5) -> W/ CD PLAYER UNIT
