Honda Ridgeline II (2016-2021) rdm/ ldw ind Wiring diagram
This page shows the only wiring diagram for the component.rdm/ ldw ind, which is found in the car Honda Ridgeline II (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rdm/ ldw ind (1 of 1)
12 PIN CONNECTOR 5 PIN CONNECTOR
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
CMBS/ FCW IND
COMPUTER DATA LINES SYSTEM
CPU/MAIN POWER SUPPLY
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 15
FUSE 26
FUSE 28
FUSE 29
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR DRIVE CIRCUIT
JOINT 3
LDW/RDM OFF SWITCH
LKAS IND
MILLIMETER WAVE RADAR
MULTIPURPOSE CAMERA UNIT
PARKING, BACKUP SENSOR/ LDW/RDM OFF SWITCH
PNK WIRE
PPL
RDM/ LDW IND
RED WIRE
RELAY ENERGIZED
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/O AC POWER OUTLET
WHT WIRE
Go to component -> Multipurpose camera circuit -> RDM/ LDW IND
