Honda Ridgeline II (2016-2021) parking, backup sensor/ldw/ rdm off switch Wiring diagrams
This page contains all the electrical diagrams for the component. parking, backup sensor/ldw/ rdm off switch, in which he is found in the car Honda Ridgeline II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
parking, backup sensor/ldw/ rdm off switch wiring diagram (1 of 3)
A/T GEAR POSITION INDICATOR PANEL LIGHT
AC INVERTER SWITCH
AUDIO REMOTE SWITCH
BLK WIRE
BLU WIRE
CABLE REEL
CARGO AREA LIGHT SWITCH
CARGO AREA LIGHT/HEATED WINDSHIELD WIPER AREA SWITCH
CRUISE CONTROL/ ACC COMBINATION SWITCH/ LKAS SWITCH
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
ECON SWITCH
GRN WIRE
GRY WIRE
HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH
HFL-SWITCH (W/O NAVIGATION)
HOMELINK UNIT
INTERIOR LIGHT SWITCH
JOINT 5
JOINT 7
PARKING, BACKUP SENSOR/LDW/ RDM OFF SWITCH
PNK WIRE
POWER MIRROR SWITCH
REAR CONTROL PANEL (IF EQUIPPED)
RED WIRE
ROOF CONSOLE MODULE
SELECT/ RESET/ INFORMATION SWITCH
VSA/CMBS OFF SWITCH
W/ NAVIGATION
W/O AC POWER OUTLET
W/O MOONROOF
W/O NAVIGATION W/ NAVIGATION W/ A/C POWER OUTLET W/O A/C POWER OUTLET
Go to component -> Instrument illumination circuit (2 of 3) -> PARKING, BACKUP SENSOR/LDW/ RDM OFF SWITCH
parking, backup sensor/ldw/ rdm off switch wiring diagram (2 of 3)
AREA NETWORK CONTROLLER
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT/CONTROLLER
COMPUTER DATA LINES SYSTEM
CPU/MAIN POWER SUPPLY
F-CAN
F-CAN H
F-CAN L
FUSE 29
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
JOINT 3
LEFT FRONT CORNER SENSOR
LEFT REAR CENTER SENSOR
LEFT REAR CORNER SENSOR
LT BLU WIRE
LT GRN WIRE
PARKING, BACKUP SENSOR CONTROL UNIT
PARKING, BACKUP SENSOR SWITCH
PARKING, BACKUP SENSOR/LDW/ RDM OFF SWITCH
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT FRONT CORNER SENSOR
RIGHT REAR CENTER SENSOR
RIGHT REAR CORNER SENSOR
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit -> PARKING, BACKUP SENSOR/LDW/ RDM OFF SWITCH
parking, backup sensor/ldw/ rdm off switch wiring diagram (3 of 3)
A/T GEAR POSITION INDICATOR PANEL LIGHT
AUDIO REMOTE SWITCH
BEVERAGE HOLDER LIGHT
BLU WIRE
CABLE REEL
CARGO AREA LIGHT SWITCH
CARGO AREA LIGHT/HEATED WINDSHIELD WIPER AREA SWITCH
CD PLAYER UNIT
CLIMATE CONTROL UNIT
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DRIVER'S FOOTWELL LIGHT
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S SEAT HEATER SWITCH
DRIVER'S VENTILATED SEAT HEATER SWITCH
ECON SWITCH
FROM AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 10)
FROM FUSE 27 (DIAGRAM 7 OF 10)
FRONT CONSOLE BOX LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT PASSENGER'S VENTILATED SEAT HEATER SWITCH
FUSE 25
FUSE 26
FUSE 37
FUSE 38
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
HOMELINK UNIT
HVAC CONTROL UNIT
INTELLIGENT TRACTION MANAGEMENT SWITCH
INTERIOR LIGHT SWITCH
JOINT 5
JOINT 6
MICU
PARKING, BACKUP SENSOR/LDW/ RDM OFF SWITCH
POWER MIRROR SWITCH
PPL
REAR CONTROL PANEL
RED/BLK WIRE
ROOF CONSOLE MODULE
SNOW SWITCH
TO AC INVERTER SWITCH (DIAGRAM 6 OF 10)
UNDER-DASH FUSE/RELAY BOX
VSA/CMBS OFF SWITCH
W/ A/C POWER OUTLET W/O A/C POWER OUTLET
W/O AC POWER OUTLET
W/O MOONROOF
Go to component -> Power distribution circuit (8 of 10) -> PARKING, BACKUP SENSOR/LDW/ RDM OFF SWITCH
