Honda Ridgeline II (2016-2021) injector control module shield wiring diagram
This page shows the only wiring diagram for the component.injector control module shield, which is found in the car Honda Ridgeline II (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
injector control module shield wiring diagram (1 of 1)
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE A
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE B
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE C
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE D
BLK WIRE
BLU WIRE
BRN WIRE
CKP SENSOR
CMP SENSOR
EGR VALVE/ EGR VALVE POSITION SENSOR
FAN CONTROL RELAY
GRN WIRE
GRY WIRE
HIGH PRESSURE FUEL PUMP SHIELD
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
INJECTOR 5 SHIELD
INJECTOR 6 SHIELD
INJECTOR CONTROL MODULE SHIELD
JOINT 1
JOINT 2
KNOCK SENSOR 1 (BANK 1) SHIELD
KNOCK SENSOR 2 (BANK 2) SHIELD
LINE PRESSURE SOLENOID VALVE A
PCM
RELAY CIRCUIT BOARD
RELAY HOLDER C
ROCKER ARM OIL CONTROL SOLENOID A (BANK 1)
ROCKER ARM OIL CONTROL SOLENOID A (BANK 2)
ROCKER ARM OIL CONTROL SOLENOID B (BANK 1)
ROCKER ARM OIL PRESSURE SWITCH A (BANK 1)
ROCKER ARM OIL PRESSURE SWITCH A (BANK 2)
SHIFT SOLENOID VALVE A
SHIFT SOLENOID VALVE B
SHIFT SOLENOID VALVE C
TOP OF ENGINE)
TRANSMISSION RANGE SWITCH
WHT WIRE
WINDSHIELD WASHER MOTOR
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER HIGH/LOW RELAY
WINDSHIELD WIPER INTERMITTENT RELAY
YEL WIRE
Go to component -> Ground distribution circuit (1 of 7) -> INJECTOR CONTROL MODULE SHIELD
