Honda Ridgeline II (2016-2021) heater pad Wiring diagrams
This page contains all the electrical diagrams for the component. heater pad, in which he is found in the car Honda Ridgeline II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram heater pad (1 of 2)
8 PIN CONNECTOR 5 PIN CONNECTOR W/ AC POWER OUTLET W/O AC POWER OUTLET
ANC/ACTIVE SOUND CONTROL UNIT
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BRN WIRE
CABLE REEL
CARGO AREA LIGHT SWITCH
CARGO AREA LIGHT/ HEATED WINDSHIELD WIPER AREA SWITCH
COMBINATION LIGHT SWITCH
CONTROL UNIT)
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER OUTER HANDLE TOUCH SENSOR/ LOCK SWITCH
DRIVER'S DOOR POCKET LIGHT
DRIVER'S POWER WINDOW MOTOR
DRIVING POSITION MEMORY SWITCH
ECON SWITCH
ELECTRIC STEERING LOCK
FUEL FILL DOOR OPENER SWITCH
GAUGE CONTROL MODULE
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
HEATED STEERING WHEEL CONTROL UNIT
HEATED STEERING WHEEL RELAY
HEATER PAD
KEYLESS ACCESS/TPMS CONTROL UNIT
LEFT BSI ALERT INDICATOR
LEFT POWER MIRROR
MICU
PARKING, BACKUP SENSOR CONTROL UNIT
POWER MIRROR CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RELAY HOLDER J FRONT ACCESSORY POWER SOCKET RELAY
STEERING ANGLE SENSOR
TRAILER ELECTRIC BRAKE 4 PIN CONNECTOR
UNDER-DASH FUSE/RELAY BOX
VENTILATED SEAT RELAY
VSA OFF SWITCH
VSA/CMBS OFF SWITCH
W/ KEYLESS ACCESS
W/O AC POWER OUTLET
Go to component -> Ground distribution circuit (2 of 7) -> HEATER PAD
Wiring diagram heater pad (2 of 2)
12 VOLT BATTERY SENSOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
CABLE REEL (TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CPU/MAIN POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
FUSE 15
FUSE 23
FUSE 27
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEATED STEERING WHEEL CONTROL UNIT
HEATED STEERING WHEEL RELAY
HEATER PAD
HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
LIN TRANSCEIVER
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RELAY HOLDER K
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Heated steering wheel circuit -> HEATER PAD
