Honda Ridgeline II (2016-2021) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Honda Ridgeline II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram blk (91 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (91 of 137)

Get access

AUXILIARY UNDER-HOOD FUSE/ RELAY BOX BLK WIRE BLU WIRE CARGO AREA LIGHT/ HEATED WINDSHIELD WIPER AREA SWITCH FUSE 15 FUSE 23 FUSE 29 GRY WIRE HEATED WINDSHIELD WIPER AREA HEATED WINDSHIELD WIPER AREA RELAY HOT AT ALL TIMES JOINT 4 LT GRN WIRE MICU OFF PNK WIRE REAR OF ENGINE COMPT) RED WIRE RELAY ENERGIZED UNDER-DASH FUSE/RELAY BOX

Go to component -> Heated windshield circuit -> BLK WIRE

Wiring diagram blk (92 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (92 of 137)

Get access

BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CONTROL UNIT) FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 2-8 2-10 FUSE 23 FUSE 29 FUSE 4 GRN WIRE GRY WIRE HOT AT ALL TIMES JOINT 4 LEFT POWER MIRROR LT BLU WIRE LT GRN WIRE MICU MOONROOF MOTOR/ CONTROL UNIT POWER DISTRIBUTION SYSTEM POWER WINDOW MASTER SWITCH REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY REAR WINDOW DEFOGGER SWITCH REAR WINDOW DEFOGGER SWITCH IND RELAY ENERGIZED RIGHT POWER MIRROR TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX W/O AC POWER OUTLET W/ AC POWER OUTLET WHT WIRE

Go to component -> Mirror heater & rear defogger circuit -> BLK WIRE

Wiring diagram blk (93 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (93 of 137)

Get access

3.3 LIN AUDIO REMOTE SWITCH AUDIO UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- COMPUTER DATA LINES SYSTEM CPU/MAIN POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER F-CAN H F-CAN L F-CAN TRANSCEIVER GAUGE CONTROL MODULE GRN WIRE GRY WIRE HANG-UP/ BACK HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH LT BLU WIRE NAVIGATION SYSTEM NCA WIRE PICK-UP PNK WIRE PPL RED WIRE SOURCE TALK TAN WIRE VOL DOWN VOL UP W/O HEATED STEERING WHEEL W/ HEATED STEERING WHEEL WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ color audio (3 of 3) -> BLK WIRE

Wiring diagram blk (94 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (94 of 137)

Get access

ANC/ACTIVE SOUND CONTROL UNIT (RIGHT SIDE OF DASH) AUDIO- NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER COMPUTER DATA LINES SYSTEM DATA LINES SYSTEM FRONT HFL-ANC/ ACTIVE SOUND CONTROL MICROPHONE GRN WIRE GRY WIRE LT BLU WIRE NCA WIRE PPL REAR ANC/ACTIVE SOUND CONTROL MICROPHONE RED WIRE TAN WIRE WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio & amplifier (2 of 6) -> BLK WIRE

Wiring diagram blk (95 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (95 of 137)

Get access

AC INVERTER ACC RELAY BLK WIRE BLU WIRE BRN WIRE CENTER SPEAKER EXCITER 1 CENTER SPEAKER EXCITER 2 FUSE 14 FUSE 2-7 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL RED WIRE RIGHT END OF DASH) STEREO AMPLIFIER (RIGHT END OF DASH) TAN WIRE UNDER-HOOD FUSE/RELAY BOX USB PORT C USB PORT D WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio & amplifier (3 of 6) -> BLK WIRE

Wiring diagram blk (96 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (96 of 137)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SPEAKER FRONT CENTER SPEAKER (+) FUSE 29 GRN WIRE GRY WIRE JOINT 3 LEFT REAR DOOR SPEAKER LEFT SPEAKER EXCITER 1 LEFT SPEAKER EXCITER 2 LEFT TWEETER LT BLU WIRE LT GRN WIRE MICU PNK WIRE PPL RED WIRE RELAY ENERGIZED RIGHT SPEAKER EXCITER 1 RIGHT SPEAKER EXCITER 2 SUBWOOFER TAN WIRE UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio & amplifier (4 of 6) -> BLK WIRE

Wiring diagram blk (97 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (97 of 137)

Get access

3.3 LIN BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CPU/MAIN POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER F-CAN H F-CAN L F-CAN TRANSCEIVER FRONT PASSENGER'S DOOR SPEAKER GAUGE CONTROL MODULE GRN WIRE GRY WIRE LT BLU WIRE PNK WIRE PPL RED WIRE REGULATOR RIGHT REAR DOOR SPEAKER RIGHT TWEETER WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio & amplifier (5 of 6) -> BLK WIRE

Wiring diagram blk (98 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (98 of 137)

Get access

AUDIO- NAVIGATION UNIT BLK WIRE BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM FM DISTRIBUTOR GPS ANTENNA (IF EQUIPPED) GRN WIRE GRY WIRE INTERIOR LIGHTS SYSTEM LINES SYSTEM LT BLU WIRE NAVIGATION SYSTEM NCA WIRE PCM REAR CAMERA CIRCUIT RED WIRE ROOF ANTENNA TAN WIRE WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio & amplifier (6 of 6) -> BLK WIRE

Wiring diagram blk (99 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (99 of 137)

Get access

AUDIO REMOTE SWITCH AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION) BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- COMPUTER DATA LINE SYSTEM DISP CHANGE DOOR LOCKS SYSTEM FUSE 14 FUSE 29 FUSE 40 GRN WIRE GRY WIRE HANG-UP/ BACK HFL SWITCH/ HEATED STEERING WHEEL SWITCH HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MENU PICK-UP PNK WIRE PPL RED WIRE SOURCE TALK TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX VOL DOWN VOL UP W/ CD PLAYER UNIT W/ NAVIGATION W/O CD PLAYER UNIT W/O NAVIGATION WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio w/o amplifier (1 of 5) -> BLK WIRE

Wiring diagram blk (100 of 137)

Wiring diagram blk for Honda Ridgeline II (2016-2021) (100 of 137)

Get access

AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION) BLK WIRE BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM FM DISTRIBUTION GPS ANTENNA (IF EQUIPPED) GRN WIRE GRY WIRE INTERIOR LIGHTS SYSTEM LINES SYSTEM LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE RED WIRE ROOF ANTENNA WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ display audio w/o amplifier (5 of 5) -> BLK WIRE

Page 10 of 14

1 2 3 4 5 6 7 8 9 10 11 12 13 14

Honda Ridgeline II (2016-2021) blk Wiring diagrams

Wiring diagram blk (91 of 137)

List of components:

Wiring diagram blk (92 of 137)

List of components:

Wiring diagram blk (93 of 137)

List of components:

Wiring diagram blk (94 of 137)

List of components:

Wiring diagram blk (95 of 137)

List of components:

Wiring diagram blk (96 of 137)

List of components:

Wiring diagram blk (97 of 137)

List of components:

Wiring diagram blk (98 of 137)

List of components:

Wiring diagram blk (99 of 137)

List of components:

Wiring diagram blk (100 of 137)

List of components:
