Honda Ridgeline II (2016-2021) ac inverter relay Wiring diagram
This page shows the only wiring diagram for the component.ac inverter relay, which is found in the car Honda Ridgeline II (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ac inverter relay (1 of 1)
AC INVERTER ACC RELAY
AC INVERTER RELAY
AC INVERTER SWITCH (LEFT SIDE OF DASH)
AC INVERTER UNIT (W/ AC POWER OUTLET) (BEHIND LEFT REAR SEAT)
ANC/ ACTIVE SOUND CONTROL UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
FROM FUSE 1-6 (DIAGRAM 1 OF 10)
FROM JOINT 5 (DIAGRAM 8 OF 10)
FUSE 1 1
FUSE 14
GRY WIRE
MICU
POWER OUTLET
RED WIRE
RELAY HOLDER D
RELAY HOLDER I
RIGHT END OF DASH)
STEREO AMPLIFIER
TAN WIRE
UNDER- HOOD FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
USB CHARGE UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 10) -> AC INVERTER RELAY
