Car Wiring Diagrams for Shift interlock circuit for Honda Ridgeline I facelift (2009-2014)

ANTI-THEFT SYSTEM APP SENSOR (RIGHT REAR OF ENGINE COMPT) ATP-P BKSW SLS ATP-P BLK WIRE BLU WIRE BLU/BLK WIRE BRAKE PEDAL POSITION SWITCH (AT TOP OF BRAKE PEDAL ARM) FUSE 13 FUSE 21 FUSE 32 GAUGE CONTROL MODULE GRN WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IG KEY SW IGNITION KEY SWITCH IGNITION KEY SWITCH/KEY LIGHT IN STEERING COLUMN) (PARK PIN SWITCH: TOP LEFT SIDE OF STEERING COLUMN) KEY INTERLOCK SOLENOID KEY SOL LOCK SOLENOID/ PARK PIN SWITCH (SHIFT LOCK SOLENOID: LT BLU WIRE MICU UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) ORG/ WIRE P-PIN PARK PIN SWITCH POWERTRAIN CONTROL (PCM) MODULE (RIGHT SIDE OF ENGINE COMPT) RED WIRE RED/WHT WIRE SHIFT LOCK SOLENOID STOP SW TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING) UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPT) VCCB APSA WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE
