Honda Ridgeline I facelift (2009-2014) vts pcs Wiring diagram
This page shows the only wiring diagram for the component.vts pcs, which is found in the car Honda Ridgeline I facelift (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vts pcs (1 of 1)
2 3 PPL
4 5 6 7 8 PPL PNK WIRE
AIR CONDITIONING SYSTEM
ALTL ALTC ALTF OPSW ATP-2 KS IMT (+) IMT (-)
ATFT EGRP ATP-1 PPL
ATP-D ATP-FWD ATP-RVS SHB LSA
BLK WIRE
BLU WIRE
BRN WIRE
ENGINE COMPT)
GRN WIRE
GRN/RED WIRE
GRY WIRE
IAT ATP-R ATP-N
ICM
KNOCK SENSOR (TOP CENTER OF (RIGHT FRONT OF ENGINE) ENGINE)
LT BLU WIRE
LT GRN WIRE
NM NC
OIL PRESSURE SWITCH (RIGHT FRONT OF ENGINE)
PDSW
PGMETCS ETCSM- ETCSM+
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF
PPL
PPL 9 10 11 12 13 14 15 16 17 18 19
PPL PNK MAP WIRE
PPL SHD CKPA CMP
PPL TPSB
RED WIRE
SHA
SHC EGR
STARTING/ CHARGING SYSTEM
TAN WIRE
TRANSMISSION FLUID PRESSURE SWITCH (ON TRANSMISSION HOUSING)
TRANSMISSION FLUID PRESSURE SWITCH A (ON TRANSMISSION HOUSING)
TRANSMISSION FLUID PRESSURE SWITCH B (ON TRANSMISSION HOUSING)
VTS PCS
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (7 of 7) -> VTS PCS
