Honda Ridgeline I facelift (2009-2014) except honda accessory Wiring diagram
This page shows the only wiring diagram for the component.except honda accessory, which is found in the car Honda Ridgeline I facelift (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except honda accessory (1 of 1)
A/C PRESSURE SWITCH
BLK WIRE
BLOWER MOTOR
BRAKE FLUID LEVEL SWITCH
CIGARETTE LIGHTER (HONDA ACCESSORY)
CONTROL BLOCK
DEFOGGER
DLC
DRIVER'S ACCESSORY POWER SOCKET BLOWER POWER TRANSISTOR
DRIVER'S SEAT HEATER SWITCH
ELD UNIT
EXCEPT HONDA ACCESSORY
FRONT PASSENGER'S ACCESSORY POWER SOCKET SELECT/ RESET SWITCH
FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH DOOR LOCK SWITCH
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
HANDSFREE LINK CONTROL UNIT (NAVIGATION: USA RTL, CANADA: TOURING)
HEATED WINDSHIELD WIPER AREA
INTERIOR LIGHT SWITCH
LEFT DRL
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT HEADLIGHT
PSP SWITCH
RELAY
RELAY CONTROL MODULE
RIGHT END OF DASH)
RIGHT POWER MIRROR (USA: RTL& CANADA)
SEAT HEATER RELAY (USA: RTL, CANADA: TOURING)
SG-1
SRS UNIT
STEERING ANGLE SENSOR
UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) MICU
UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPT)
USA: RTL, CANADA: TOURING
VSA MODULATOR CONTROL UNIT
WASHER MOTOR RELAY
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (2 of 5) -> EXCEPT HONDA ACCESSORY
