Car Wiring Diagrams for Music link circuit for Honda Ridgeline I (2005-2009)

AUD L (+) AUDIO GND AUD R (+) ACC POWER DOCK TX DOCK RX SHIELDED WIRE AUD L (-) AUD L (+) AUD R (-) AUD R (+) GA-NET SYSTEM ACC BUS (-) BUS (+) AUD R- AUD L- AUDIO UNIT BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BUS (+) BUS (-) GA-NET GND F/W POWER GA-NET SYSTEM ACC BUS SH AUD SH AUD R (+) AUD L (+) SHIELDED WIRE SHIELDED WIRE GRN WIRE HONDA MUSIC LINK UNIT MUSIC LINK CONNECTOR ORG/ WIRE ORG/BLK WIRE RED WIRE RED/BLK WIRE SHIELDED WIRE WHT WIRE YEL WIRE
