Honda Ridgeline I (2005-2009) Courtesy lamps circuit

BLK WIRE BLU WIRE BLU/RED WIRE CEILING LIGHT CONSOLE BOX LIGHT 1 COURTESY LT AS COURTESY LT DR COURTESY LT LR COURTESY LT RR DOOR DRIVER'S DOOR COURTESY LIGHT DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR) DRIVER'S VANITY MIRROR LIGHT DRSWAS DRSWDR DRSWRA DRSWRD FRONT INDIVIDUAL MAP LIGHTS FRONT PASSENGER'S DOOR COURTESY LIGHT FRONT PASSENGER'S DOOR SWITCH (ON RIGHT "B" PILLAR) FRONT PASSENGER'S VANITY MIRROR LIGHT FUSE 6 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INTERIOR LIGHT SWITCH INTRLT LEFT LEFT REAR DOOR COURTESY LIGHT LEFT REAR DOOR SWITCH (ON LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE MICU OFF ON OFF DOOR RED WIRE RIGHT RIGHT REAR DOOR COURTESY LIGHT RIGHT REAR DOOR SWITCH (ON RIGHT "C" PILLAR) UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) WHT WIRE WHT/BLU WIRE YEL WIRE
