Car Wiring Diagrams for Immobilizer circuit for Honda Ridgeline I (2005-2009)

+B BACK UP BLK WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) FUEL PUMP FUSE 19 FUSE 7 GAUGE CONTROL MODULE GND GND GND GND GRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBI CODE DIAG-H H/BRAKE SW IMMOBI ALARM IMMOBILIZER INDICATOR IMMOBILIZER RECEIVER UNIT (IN STEERING COLUMN, ON IGNITION KEY CYLINDER) IMOES UNIT (2007-08 CANADA, 2008 USA) J/C KEY SW +B MICU IG KEY SW ORG/ WIRE PCM (RIGHT REAR OF ENGINE COMPARTMENT) PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 PWR IN IGN IN FUEL PUMP CTRL RLY CTRL LOGIC GND IMMOBI CODE IN RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE TRANSMISSIONS SYSTEM UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
