Honda Ridgeline I (2005-2009) right taillight assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right taillight assembly, in which he is found in the car Honda Ridgeline I (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right taillight assembly (1 of 3)
ATP-R
BACK LT-
BACKUP LIGHTS DIODE (UNDER MIDDLE OF DASH)
BLK WIRE
FUSE 21
GAUGE CONTROL MODULE
GRN WIRE
GRN/BLK WIRE
HOT IN ON OR START
J/C
LEFT BACK-UP LIGHT
LEFT TAILLIGHT ASSEMBLY
MICU
ORG/ WIRE
PCM (RIGHT REAR OF ENGINE COMPARTMENT)
RIGHT BACK-UP LIGHT
RIGHT TAILLIGHT ASSEMBLY
TRAILER CONNECTOR
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL)
WHT WIRE
Go to component -> Back-up lamps circuit -> RIGHT TAILLIGHT ASSEMBLY
Wiring diagram right taillight assembly (2 of 3)
1-BRAKE 2-TAIL
1-BRAKE 2-TAIL RIGHT LICENSE PLATE LIGHT
B-CAN
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CARGO AREA LIGHT RELAY
CARGO LT RLY
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
FUSE 1
FUSE 21
FUSE 30
FUSE 7
GRN WIRE
GRN/RED WIRE
GRY/YEL WIRE
HAZ SW
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HEAD PARK
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IN-BED TRUNK LID ACTUATOR/ LATCH SWITCH (IN-BED TRUNK LID)
IN-BED TRUNK LID LATCH SWITCH
INTERIOR LIGHTS, NAVIGATION SYSTEMS
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT ASSEMBLY
LT GRN WIRE
LT SW CARGO
MICU VBU
OFF
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT ASSEMBLY
SG-1
STOP SW
SW TAILGATE
SW TRUNK
TAILGATE SWITCH (RIGHT REAR OF CARGO AREA)
TURN R TURN L
TURN SIGNAL LIGHT SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/ RELAY BOX (AT LEFT KICK PANEL)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WIPER/WASHER SWITCH
YEL WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps & trailer connector circuit (1 of 3) -> RIGHT TAILLIGHT ASSEMBLY
Wiring diagram right taillight assembly (3 of 3)
BACK WINDOW POSITION SWITCH
BLK WIRE
BRN WIRE
IN-BED TRUNK LID ACTUATOR/ LATCH SWITCH
IN-BED TRUNK LID HANDLE SWITCH
IN-BED TRUNK LID KEY CYLINDER SWITCH (RTS, RTL, EX-L)
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT CARGO AREA LIGHT 1
LEFT CARGO AREA LIGHT 2
LEFT LICENSE PLATE LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT ASSEMBLY
ORG/ WIRE
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT CARGO AREA LIGHT 1
RIGHT CARGO AREA LIGHT 2
RIGHT LICENSE PLATE LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT ASSEMBLY
RTX
TAILGATE SWITCH
TRAILER CONNECTOR 1
TRAILER CONNECTOR 2
WHT WIRE
Go to component -> Ground distribution circuit (5 of 5) -> RIGHT TAILLIGHT ASSEMBLY
