Honda Ridgeline I (2005-2009) reference voltage Wiring diagram

APP SENSOR (RIGHT REAR OF ENGINE COMPARTMENT) BLK WIRE BLU WIRE BLU/YEL WIRE BRAKE PEDAL POSITION SWITCH (AT TOP OF BRAKE PEDAL ARM) BRN WIRE BRN/YEL WIRE COMMUNICATION SIGNAL HIGH COMMUNICATION SIGNAL LOW COMPUTER DATA LINES SYSTEM CONTROL BLOCK CRUISE CONTROL MAIN SWITCH CRUISE CONTROL MAIN SWITCH LIGHT DRIVE INPUT ENGINE CONTROLS SYSTEM FUSE 13 FUSE 18 FUSE 7 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND HORN RELAY HOT AT ALL TIMES HOT IN ON OR START IGNITION INPUT LT GRN WIRE ON INDICATOR ORG/ WIRE OUTPUT SHAFT (COUNTER SHAFT) SPEED SENSOR (ON TRANSMISSION HOUSING) POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPARTMENT) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE REFERENCE VOLTAGE RELAY CONTROL RELAY CONTROL MODULE SENSOR GROUND SENSOR INPUT SENSOR VOLTAGE SWITCH INPUT THROTTLE ACTUATOR TP SENSOR A SIGNAL TP SENSOR B SIGNAL TP SENSOR/THROTTLE ACTUATOR (ON SIDE OF THROTTLE BODY ASSEMBLY) UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPARTMENT) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
