Honda Ridgeline I (2005-2009) drl relay switch Wiring diagram
This page shows the only wiring diagram for the component.drl relay switch, which is found in the car Honda Ridgeline I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drl relay switch (1 of 1)
BLK WIRE
BLOWER POWER TRANSISTOR
BRAKE LIGHT NOISE CONDENSER
CARGO AREA LIGHT SWITCH
CLIMATE CONTROL UNIT
CRUISE CONTROL MAIN SWITCH
DLC
DRIVER'S ACCESSORY POWER SOCKET
DRIVER'S SEAT HEATER SWITCH
DRL RELAY SWITCH
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH DOOR LOCK SWITCH
FRONT PASSENGER'S SEAT HEATER SWITCH
GAUGE CONTROL MODULE
GAUGE CONTROL UNIT
GLOVE BOX LIGHT
HEATED WINDSHIELD WIPER AREA DEFOGGER
HEATER CONTROL UNIT- PANEL
IGNITION KEY SWITCH/ KEY LIGHT
INTERIOR LIGHT SWITCH
LOW BEAM CUT RELAY
MES CONNECTOR
MOONROOF PARK PIN SWITCH SWITCH (EX-L, RTL)
NAVIGATON DISPLAY UNIT
RIGHT POWER MIRROR
RTL, EX-L, LX
RTS, RTL EX-L, LX
RTX
RTX, EX-L
RTX, RT, LX
SELECT/ RESET SWITCH
TPMS CONTROL UNIT
TRAILER LIGHTING RELAY 1 (RTX)
TRAILER LIGHTING RELAY 2 TRAILER LIGHTING CONTROL UNIT
UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL)
VSA OFF SWITCH
Go to component: -> Ground distribution circuit (3 of 5) -> DRL RELAY SWITCH
