Honda Ridgeline I (2005-2009) charging system indicator drive circuit Wiring diagram
This page shows the only wiring diagram for the component.charging system indicator drive circuit, which is found in the car Honda Ridgeline I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram charging system indicator drive circuit (1 of 1)
ALT ALT ALT
ALTERNATOR
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
CHARGING SYSTEM INDICATOR DRIVE CIRCUIT
COMPUTER DATA LINES SYSTEM
ELD CAN CAN IN- CTRL FR PUT SIG SIG SIG
ELD UNIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 18
FUSE 21
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION INPUT
KICK PANEL)
LOAD OUTPUT
MULTI- FUSE 22
PCM (RIGHT REAR OF ENGINE COMPARTMENT)
POWER DISTRIBUTION SYSTEM
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
STARTING CIRCUIT
TRANSMISSION
UNDER-DASH FUSE/RELAY BOX (AT LEFT
UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPARTMENT)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component: -> Charging circuit -> CHARGING SYSTEM INDICATOR DRIVE CIRCUIT
