Trunk, tailgate, fuel door circuit for Honda Ridgeline I (2004-2009)
Trunk, tailgate, fuel door circuit
B+ DOOR LOCK VBU
BLK WIRE
BLU WIRE
FUSE 21
FUSE 7
FUSE 8
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IN-BED TRUNK LID HANDLE SWITCH (IN-BED TRUNK LID)
IN-BED TRUNK LID LATCH SWITCH
IN-BED TRUNK LID MAIN SWITCH
MULTI- PLEX CON- TROL UNIT
ORG/ WIRE
RED WIRE
TAILGATE SW
TAILGATE SWITCH (RIGHT REAR OF CARGO AREA)
TRUNK ACT
TRUNK HANDLE SW
TRUNK SW
TRUNK UNLOCK
UNDER-DASH FUSE/ RELAY BOX (AT LEFT KICK PANEL)
WHT WIRE
YEL WIRE
