Car Wiring Diagrams for Heated seats circuit for Honda Ridgeline I (2004-2009)

BACK HEATER BLK WIRE BLK/YEL WIRE BRN WIRE CIRCUIT BREAKER CIRCUIT THERMOSTAT BREAKER CUSHION HEATER DRIVER'S SEAT HEATER (IN DRIVER'S SEAT) DRIVER'S SEAT HEATER SWITCH FRONT PASSENGER'S SEAT HEATER FRONT PASSENGER'S SEAT HEATER SWITCH FUSE 11 FUSE 30 GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON INDICATORS HIGH LOW ON INDICATORS HIGH LT GRN WIRE ORG/ WIRE RED WIRE RED/BLK WIRE SEAT HEATER RELAY SEAT HEATER SWITCH LIGHT THERMOSTAT UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (AT RIGHT REAR OF ENGINE COMPARTMENT)
