Honda Ridgeline I (2004-2009) video monitor console Wiring diagrams
This page contains all the electrical diagrams for the component. video monitor console, in which he is found in the car Honda Ridgeline I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram video monitor console (1 of 2)
10 11 12 13 14 15 16 17 18 19 BATTERY IN (+B) REMOTE GND
3 2 1 SHIELD (AM/FM) ANT +B SIG
AM/FM ANTENNA AMPLIFIER (REAR OF ROOF)
ANTENNA OUTPUT POWER INPUT SHIELD
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CABLE REEL
CEILING LIGHT
CHANNEL DOWN SWITCH
CHANNEL UP SWITCH
DRIVER'S DOOR SPEAKER
DVD PLAYER UNIT
FM MODU- LATOR
FREQUENCY MODULATOR UNIT DIN TERM
FRONT PASSENGER'S DOOR SPEAKER
FUSE 32
FUSE 5 FUSE 6
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
I-VES TERM
LEFT
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
LT GRN/RED WIRE
LT PPL
LT PPL PPL
MICU
MODE SWITCH
PPL
RADIO REMOTE SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
ROOF ANTENNA
RR L SPKR (-) RR L SPKR (+)
RR R SPKR (-) RR L SPKR (-) FR R SPKR (-) FR L SPKR (-) ILLUM (-)
SUBWOOFER (IF EQUIPPED)
UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL)
VIDEO MONITOR CONSOLE
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Rear seat entertainment circuit, except rtl -> VIDEO MONITOR CONSOLE
Wiring diagram video monitor console (2 of 2)
AM/FM ANTENNA AMPLIFIER (REAR OF ROOF)
ANTENNA OUTPUT POWER INPUT SHIELD
AUD R- AUD L-
AUD SH AUD R (+) AUD L (+)
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CEILING LIGHT
DIN TERM
DRIVER'S DOOR SPEAKER
DVD PLAYER UNIT
FM MODU- LATOR
FREQUENCY MODULATOR UNIT
FRONT PASSENGER'S DOOR SPEAKER
FUSE 32
FUSE 5
FUSE 6
GA NET GND
GA-NET ACC
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
I-VES TERM
LEFT
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
LT GRN/RED WIRE
LT PPL
LT PPL PPL
MICU
ORG/ WIRE
PNK WIRE
PPL
PPL PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
ROOF ANTENNA
RR L SPKR (-) RR L SPKR (+)
RR R SPKR (-) RR L SPKR (-) FR R SPKR (-) FR L SPKR (-) ILLUM (-) GND
SHIELD (AM/FM) ANT +B SIG
SUBWOOFER
UNDER-DASH FUSE/RELAY BOX (AT LEFT KICK PANEL)
VIDEO MONITOR CONSOLE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Rear seat entertainment circuit, rtl without navigation (1 of 2) -> VIDEO MONITOR CONSOLE
