Honda Ridgeline I (2004-2009) front a/f sensor shield and front secondary Wiring diagram
This page shows the only wiring diagram for the component.front a/f sensor shield and front secondary, which is found in the car Honda Ridgeline I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front a/f sensor shield and front secondary (1 of 1)
A/T CLUTCH PRESSURE SOLENOID VALVE A
A/T CLUTCH PRESSURE SOLENOID VALVE B
A/T CLUTCH PRESSURE SOLENOID VALVE C
AUXILIARY UNDER-HOOD RELAY BOX (RIGHT REAR OF ENGINE COMPT)
BATTERY
BLK WIRE
BRAIDED WIRE
BRN WIRE
CKP SENSORS (A, B)
CMP SENSOR
EGR VALVE/ EGR VALVE POSITION SENSOR
ENGINE
FAN CONTROL RELAY
FRONT A/F SENSOR SHIELD AND FRONT SECONDARY
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
J/C
KNOCK SENSOR SHIELD
PCM
RADIATOR FAN MOTOR
REAR A/F SENSOR SHIELD AND REAR SECONDARY
RIGHT HEADLIGHT (USA)
ROCKER ARM OIL PRESSURE SWITCH (VTEC OIL PRESSURE SWITCH)
SECURITY HOOD SWITCH RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
TP SENSOR/ THROTTLE ACTUATOR SHIELD
TRANS- MISSION RANGE SWITCH
TRANSMISSION
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER MOTOR
YEL WIRE
Go to component: -> Ground distribution circuit (1 of 5) -> FRONT A/F SENSOR SHIELD AND FRONT SECONDARY
