Honda Ridgeline I (2004-2009) atp fwd shc lsa shb sha atft atp-r atp-n atp-d atp-2 atp-1 altc Wiring diagram

This page shows the only wiring diagram for the component.atp fwd shc lsa shb sha atft atp-r atp-n atp-d atp-2 atp-1 altc, which is found in the car Honda Ridgeline I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram atp fwd shc lsa shb sha atft atp-r atp-n atp-d atp-2 atp-1 altc (1 of 1)

Wiring diagram atp fwd shc lsa shb sha atft atp-r atp-n atp-d atp-2 atp-1 altc for Honda Ridgeline I (2004-2009)

Get access

1 13 14 15 16 17 18 19 23 25 28 30 31 32 33 34 38 40 41 PGMETCS A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE A (ON TRANSMISSION HOUSING) ALTF ATF TEMPERATURE SENSOR (ON TRANSMISSION HOUSING) ATP FWD SHC LSA SHB SHA ATFT ATP-R ATP-N ATP-D ATP-2 ATP-1 ALTC BLK WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE GRN WIRE GRN/WHT WIRE GRN/YEL WIRE ORG/ WIRE PNK WIRE POWERTRAIN (PCM) CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) RED WIRE RED/BLK WIRE SHIFT CONTROL SOLENOID VALVE A SHIFT CONTROL SOLENOID VALVE B STARTING/ CHARGING SYSTEM TRANSMISSION FLUID PRESSURE SWITCH (ON TRANSMISSION HOUSING) WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE

Go to component: -> A/t circuit (3 of 3) -> ATP FWD SHC LSA SHB SHA ATFT ATP-R ATP-N ATP-D ATP-2 ATP-1 ALTC
