Car Wiring Diagrams for Radio circuits for Honda Prelude V (1996-2001)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 PNK WIRE ACCESSORY POWER SOCKET RELAY (ABOVE UNDERDASH FUSE/RELAY BOX, ON BRACKET) AUDIO UNIT BLK WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAIDED WIRE BRN/BLK WIRE BRN/WHT WIRE CLOCK RADIO FUSE 43 FUSE 18 GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ACC OR ON INTERIOR LIGHTS FUSE 46 LEFT FRONT SPEAKER LEFT FRONT TWEETER LEFT REAR MICROPHONE LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE NCA WIRE PNK WIRE REAR WINDOW ANTENNA RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT SPEAKER RIGHT FRONT TWEETER RIGHT REAR MICROPHONE RIGHT REAR SPEAKER RR SPEAKER FUSE 5 STEREO AMPLIFIER UNDERDASH FUSE/RELAY BOX UNDERHOOD FUSE/RELAY BOX WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/RED WIRE YEL/WHT WIRE
