Headlight circuit, without drl for Honda Prelude V (1996-2001)
Headlight circuit, without drl (1 of 2)
BATTERY FUSE 32
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIMMER RELAY
DIMMER SWITCH
FLASH TO PASS SWITCH
GAUGE ASSEMBLY
HEAD
HEADLIGHT RELAY
HEADLIGHT SWITCH
HIGH BEAM INDICATOR LIGHT
HIGH LOW
HOT AT ALL TIMES
J/C
LEFT HEADLIGHT
LEFT HEADLIGHT FUSE 51
LO HI
LT GRN/RED WIRE
OFF PARK
ORG/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
RIGHT HEADLIGHT FUSE 50
TO FOGLIGHT RELAY 1 (DIAGRAM 2 OF 2)
TO FOGLIGHT RELAY 2 (DIAGRAM 2 OF 2)
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
W/ FOG- LIGHTS
W/O FOG- LIGHTS
WIPER/WASHER SYSTEM
Headlight circuit, without drl (2 of 2)
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIODE 1 (BEHIND LEFT SIDE OF DASH)
DIODE 2 (BEHIND LEFT SIDE OF DASH)
DIODE 3 (LEFT KICK PANEL)
FOG LIGHT SWITCH
FOGLIGHT IN-LINE FUSE HOLDER (LEFT KICK PANEL)
FOGLIGHT RELAY 1 (BEHIND LEFT SIDE OF DASH)
FOGLIGHT RELAY 2 (BEHIND DRIVER'S LEFT AIR VENT)
FROM COMBINATION LIGHT SWITCH (DIAGRAM 1 OF 2)
FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
FUSE BOX FUSE 36
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT FOGLIGHT
OFF HEAD
ORG/ WIRE
PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOGLIGHT
SMALL LIGHT FUSE 42
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
