Exterior lamps circuit for Honda Prelude V (1996-2001)
Exterior lamps circuit (1 of 2)
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/ WHT WIRE
BRAKE SWITCH (BEHIND DASH, ON TOP OF BRAKE PEDAL SUPPORT)
BULB TYPE
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
GRN/ WHT WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD OFF PARK
HEADLIGHT SWITCH (PART OF COMBINATION LIGHT SWITCH)
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT (TYPE SH)
HOT AT ALL TIMES
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAIL LIGHT
LICENSE PLATE LIGHT
RED/ BLK WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL LIGHT
SECURITY SYSTEM CONNECTOR (CANADA)
SMALL LIGHT FUSE 42
STOP HORN FUSE 41
TAIL LIGHT FUSE 10
TO UNDERDASH FUSE/RELAY BOX (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR (ON LEFT REAR OF TRUNK, TAPED TO HARNESS)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
W/ SPOILER
WHT GRN/ WIRE
WHT YEL/ WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL/ WHT WIRE
Exterior lamps circuit (2 of 2)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
COMBINATION LIGHT SWITCH
FLASHER
FROM LEFT FRONT TURN SIGNAL
FROM LEFT REAR TURN SIGNAL
FROM RIGHT FRONT TURN SIGNAL (DIAGRAM 1 OF 2)
FROM RIGHT REAR TURN SIGNAL (DIAGRAM 1 OF 2)
GAUGE ASSEMBLY
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HAZARD FUSE 39
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
LEFT
LEFT CTRL
LEFT TURN SIGNAL INDICATOR LIGHT
METER CRUISE CONTROL FUSE 13
OFF
RED WIRE
RED/BLK WIRE
RIGHT
RIGHT CTRL
RIGHT TURN SIGNAL INDICATOR LIGHT
TURN SIGNAL LIGHT DIODE (ABOVE UNDERDASH FUSE/RELAY BOX, TAPED TO HARNESS)
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT/GRN WIRE
YEL WIRE
