Back-up lamps circuit for Honda Prelude V (1996-2001)
Back-up lamps circuit
5 3 (1999-01)
A/T
A/T GEAR POSITION SWITCH (ON LOWER REAR OF TRANSAXLE)
A/T REVERSE RELAY (ABOVE UNDERDASH FUSE/RELAY BOX, ON BRACKET)
ATTS CONTROL UNIT (TYPE SH) (ON UNDERSIDE OF FRONT PASSENGER'S FOOTREST)
BACK-UP LIGHT SWITCH (ON TOP FRONT OF TRANSAXLE)
BLK WIRE
GRN WIRE
GRN/BLK WIRE
HOT IN ON OR START METER (CRUISE CONTROL) FUSE 13
LEFT BACK-UP LIGHT
M/T
RED/WHT WIRE
RIGHT BACK-UP LIGHT
TRAILER LIGHTING CONNECTOR (ON LEFT REAR OF TRUNK, TAPED TO HARNESS)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
