Honda Prelude V (1996-2001) small light fuse 42 Wiring diagrams
This page contains all the electrical diagrams for the component. small light fuse 42, in which he is found in the car Honda Prelude V (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
small light fuse 42 wiring diagram (1 of 5)
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/ WHT WIRE
BRAKE SWITCH (BEHIND DASH, ON TOP OF BRAKE PEDAL SUPPORT)
BULB TYPE
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
GRN/ WHT WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD OFF PARK
HEADLIGHT SWITCH (PART OF COMBINATION LIGHT SWITCH)
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT (TYPE SH)
HOT AT ALL TIMES
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAIL LIGHT
LICENSE PLATE LIGHT
RED/ BLK WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL LIGHT
SECURITY SYSTEM CONNECTOR (CANADA)
SMALL LIGHT FUSE 42
STOP HORN FUSE 41
TAIL LIGHT FUSE 10
TO UNDERDASH FUSE/RELAY BOX (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR (ON LEFT REAR OF TRUNK, TAPED TO HARNESS)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
W/ SPOILER
WHT GRN/ WIRE
WHT YEL/ WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL/ WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> SMALL LIGHT FUSE 42
small light fuse 42 wiring diagram (2 of 5)
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIODE 1 (BEHIND LEFT SIDE OF DASH)
DIODE 2 (BEHIND LEFT SIDE OF DASH)
DIODE 3 (LEFT KICK PANEL)
FOG LIGHT SWITCH
FOGLIGHT IN-LINE FUSE HOLDER (LEFT KICK PANEL)
FOGLIGHT RELAY 1 (BEHIND LEFT SIDE OF DASH)
FOGLIGHT RELAY 2 (BEHIND DRIVER'S LEFT AIR VENT)
FROM COMBINATION LIGHT SWITCH (DIAGRAM 1 OF 2)
FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
FUSE BOX FUSE 36
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT FOGLIGHT
OFF HEAD
ORG/ WIRE
PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOGLIGHT
SMALL LIGHT FUSE 42
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
Go to component -> Headlight circuit, with drl (2 of 2) -> SMALL LIGHT FUSE 42
small light fuse 42 wiring diagram (3 of 5)
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIODE 1 (BEHIND LEFT SIDE OF DASH)
DIODE 2 (BEHIND LEFT SIDE OF DASH)
DIODE 3 (LEFT KICK PANEL)
FOG LIGHT SWITCH
FOGLIGHT IN-LINE FUSE HOLDER (LEFT KICK PANEL)
FOGLIGHT RELAY 1 (BEHIND LEFT SIDE OF DASH)
FOGLIGHT RELAY 2 (BEHIND DRIVER'S LEFT AIR VENT)
FROM COMBINATION LIGHT SWITCH (DIAGRAM 1 OF 2)
FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
FUSE BOX FUSE 36
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT FOGLIGHT
OFF HEAD
ORG/ WIRE
PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOGLIGHT
SMALL LIGHT FUSE 42
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
Go to component -> Headlight circuit, without drl (2 of 2) -> SMALL LIGHT FUSE 42
small light fuse 42 wiring diagram (4 of 5)
A/T GEAR POSITION CONSOLE LIGHT
ASHTRAY LIGHT
AUDIO UNIT ILLUM IN LIGHTS ON INPUT
BLK WIRE
CLOCK
COMBINATION LIGHT SWITCH
CRUISE CONTROL DIMMING CIRCUIT
D-A LINE
DASH LIGHTS BRIGHTNESS CONTROLLER
DASH LIGHTS BRIGHTNESS CONTROLLER INPUT
DIM CONTROL
DIMMING CIRCUIT
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S SEAT HEATER SWITCH (CANADA)
FUSE 20 (NOT USED)
GAUGE ASSEMBLY
GAUGE LIGHTS (2)
GRN WIRE
GROUND
HAZARD WARNING SWITCH CRUISE CONTROL MAIN SWITCH
HEAD OFF PARK
HEADLIGHT SWITCH
HEATER CONTROL PANEL
HOT AT ALL TIMES
J/C
LIGHTS ON INPUT
LT GRN WIRE
MOON- ROOF SWITCH
PASSENGER'S MULTIPLEX CONTROL UNIT (RIGHT KICK PANEL)
PASSENGER'S SEAT HEATER SWITCH (CANADA)
PNK A-D LINE WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SHIFT INDICATOR CIRCUIT A/T GEAR POSITION INDICATOR
SMALL LIGHT FUSE 42
TAIL LIGHT FUSE 10
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit -> SMALL LIGHT FUSE 42
small light fuse 42 wiring diagram (5 of 5)
3 5 (1997-98) (1999)
4 10 (1997-98) (1999-01)
A/C COMPRESSOR CLUTCH RELAY
A/T ONLY
ACCESSORY POWER SOCKET
ACCESSORY POWER SOCKET RELAY (LEFT KICK PANEL)
AUDIO UNIT
BLK WIRE
BLU WIRE
CLOCK
CLOCK RADIO FUSE 43
COMBINATION LIGHT SWITCH
CONDENSER FAN FUSE 45
CONDENSER FAN RELAY
COOLING FAN FUSE 47
DATA LINK CONNECTOR CEILING LIGHT/ SPOTLIGHTS
DOOR LOCK FUSE 44
DOOR LOCK RELAY
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S DOOR COURTESY LIGHT PASSENGER'S DOOR COURTESY LIGHT
DRIVER'S MULTIPLEX CONTROL UNIT
ENGINE CONTROL MODULE
FROM FUSE 33 (DIAGRAM 2 OF 5)
FROM FUSE 45 (DIAGRAM 3 OF 5) INTERIOR LIGHTS FUSE 46
FROM IGNITION SWITCH (DIAGRAM 2 OF 5)
FUSE 18 SHIFT LOCK SOLENOID (A/T)
GAUGE ASSEMBLY
GRN WIRE
HEADLIGHT RELAY
HEATER CONTROL PANEL
J/C
KEYLESS RECEIVER UNIT
PASSENGER'S MULTIPLEX CONTROL UNIT
RADIATOR FAN RELAY
RED WIRE
RED/GRN WIRE
SECURITY SYSTEM CONTROL UNIT CONNECTOR (CANADA)
SMALL LIGHT FUSE 42
SRS FUSE BLOCK
TO FUSE 46 (DIAGRAM 3 OF 5)
TRANSMISSION CONTROL MODULE
TRUNK LIGHT
UNDER- HOOD FUSE/ RELAY BOX
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (3 of 5) -> SMALL LIGHT FUSE 42
