Honda Prelude V (1996-2001) shift indicator circuit Wiring diagram

1 IND 2 IND A/T A/T GEAR POSITION INDICATOR ABS CONTROL UNIT (BEHIND RIGHT KICK PANEL) ABS IND CIRCUIT ABS IND. BLK WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR CAP) BRAKE/ PARK INPUT CANADA CRUISE CONTROL DIMMING CIRCUIT CRUISE CONTROL UNIT (BEHIND DASH, ABOVE ACCELERATOR PEDAL) VSS INPUT CRUISE IND DAYTIME RUNNING LIGHTS (DRL) CONTROL UNIT (BEHIND DASH, ABOVE ACCELERATOR PEDAL) DIMMING CIRCUIT DISPLAY DRIVER'S MULTIPLEX CONTROL UNIT DRL IND ENGINE CONTROL MODULE (ECM) (ON UNDERSIDE OF FRONT PASSENGER'S FOOTREST) ENGINE OIL PRESSURE SWITCH (ON LOWER LEFT OF ENGINE, BELOW OIL FILTER) ENGINE OIL PRESSURE SWITCH INPUT FROM FROM BRAKE IND (DIAGRAM 1 OF 2) GAUGE ASSEMBLY GAUGE LIGHTS (2) GRN WIRE GRN/RED WIRE GRN/WHT WIRE HIGH BEAM IND IGN IMMOBILIZER IND LEFT TURN IND N IND ORG/ WIRE P IND PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) R IND RED WIRE RIGHT TURN IND SHIFT INDICATOR CIRCUIT SOLID STATE SRS IND SRS IND CIRCUIT TRANSMISSION CONTROL MODULE (TCM) (ON UNDERSIDE OF FRONT PASSENGER'S FOOTREST) TRUNK LATCH SWITCH (ON CENTER OF TRUNK LID, AT LATCH ASSEMBLY) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) USA VEHICLE SPEED SENSOR (VSS) (ON TOP LEFT OF TRANSAXLE) VSS OUTPUT VSS INPUT WHT WIRE YEL WIRE YEL/RED WIRE
